• 360° vertical rotation
• Vertical rotation speed range: 5 to 30 rpm
• Timer with audible alarm and automatic switch-off
• Very easy to operate with simple controls and easy to view LED screen
• Reliable and extremely quiet motor produces regulated rotation throughout the speed range
• Compact with a low profile and small footprint – fits neatly into the workspace
• Platform accommodating 22 tubes (up to 15mm diameter) is included as standard.

Stirrer Shaft for Achiever 5000 Series - 40x0.7 cm, Propeller
Metal Grade: 316 Stainless Steel - Medical Grade

• Motion: Orbital, 25 mm
• Capacity: 45.4 kg
• Speed Range: 15 rpm √¢‚Ǩ‚Äú 500 rpm
• Load sensor detects unbalanced conditions and automatically reduces to a safe speed
• Applications: Cell Cultures, Solubility Studies, Extractions, Bacteria & Yeast Cultures and Suspensions, Staining/Destaining, Immunoassays, Protein Studies, Blotting Techniques

Grant Instruments TS-DW Deep well plate Thermoshaker designed for shaking and heating of deep well plates. A multisystem principle, used in the design of the thermoshaker allows it to operate as 3 independent devices:

• Incubator
• Plate shaker
• Thermoshaker

Blocks sold separately

• 360° vertical rotation – creates long wave motion for mixing large particles
• Reciprocation – creates long and medium wave motion for medium and large particles
• Vibration – creates short wave motion for mixing for small particles
• 360° vertical rotation, reciprocation and vibration can be set for continuous or timed operation, or linked together in different combinations to ensure optimum mixing conditions for your application
• Choice of two models – PTR-35 or PTR-60 – with different speeds and microtube capacities
• Vertical rotation speed: 1 to 100 rpm
• Reciprocal rotation: 1 to 90° turning angle
• Vibration: programmable in a burst of 1 to 5 seconds
• Very easy to operate, with simple set-up of multi-segment programs via push buttons and the 2-line LCD status display, fully programmable sequence of functions, including pause
• Capacity of up to 26 (PTR-35), 48 (PTR-60) microtubes and a maximum rotating speed of up to 100 rpm.
• Optional accessory platform for accommodating tubes of different diameters

Grant Instruments PCMT PLUS provides intensive mixing and temperature control of samples in microtubes or PCR plates. This model differs from the PCMT and PHMT with features including cooling and the ability to control 7 units to a PC via Bluetooth®.

• Temperature setting range: + 25℃ to 100℃
• Temperature stability ± 0.1℃, temperature uniformity ± 0.2℃ due to the bi-directional heating system (platform and lid)
• Shaking speed: 250 to 1200rpm
• Rapid heat-up
• Continuous or timed operation, with alarm buzzer and automatic switch-off facility
• Choice of two models with capacity for two (PHMP) or four (PHMP-4) 96- or 384-well microplates
• The heated lid completely covers the flat heating plate to provide bi-directional heating and excellent temperature stability and uniformity, whilst preventing condensation
• Combination of bi-directional heating and powerful orbital shaking capability produces the maximum yield from incubations
• Very easy to operate, with simple set-up of temperature, shaking speed and time via push buttons and the 2-line LCD status display

Stirrer Shaft for Achiever 5000 Series - 45x0.7 cm, Anchor Blade

• Stirring Speed Range: 6-400 rpm (I), 30-2000 rpm (II)
• Stirring Volume (H2O): up to 100l
• Maximum Viscosity (cP or mPa's): 100 000
• Maximum Torque (Ncm): 200
• Application: Stirring, dissolving, dispersion, emulsification and homogenisation in the food and beverage, cosmetic, paint/coatings, pharmaceutical, chemical, glue/adhesive, plastics/polymer and cement/construction industries. Used for pilot scale in manufacturing.
• Construction: Sealed aluminium housing with IP54 ingress protection rating, Keyless Chuck for simple, one-hand operation, brushless motor for quiet operation, and main power switch
• Display: Bright LED digital display for speed, real time torque tendency LED indicator bar, and integrated timer

• Adjustable speed control: 750 to 3000 rpm
• ‘Continuous' or ‘touch' operation
• For tubes up to 20 mm diameter
• Pressure-sensitive cup accommodates tubes up to 20mm diameter
• Reliable and extremely quiet motor produces regulated and reproducible agitation throughout the speed range
• Extremely easy to operate – select either ‘continuous' or ‘touch' operation and turn the knob to adjust the speed from 750 rpm to 3000 rpm
• In ‘touch' mode, agitation starts in response to pressure on the pressure-sensitive cup.
• Exceptionally compact with a low profile and small footprint – fits into almost any location
• Rubber suction pads hold tight to the work surface and prevent the unit from ‘walking' – they also absorb vibration and prevent its transmission to the workbench

• Adjustment knob with dial markings for variable speed control
• Secure mixing - microplate adapter unique mode of attachment
• Can be run in 4 to 40℃ (39 to 104∞F), 20% to 85% relative humidity, non-condensing conditions
• Consistent mixing speed
• Microprocessor control
• Construction: Cycoloy
• Applications: ELISA Assays, PCR Preparations, Digestions, Cell Disruptions

• The temperature range is from 5 ℃ above ambient up to +80 ℃ with temperature uniformity of ±0.3 ℃ at 37 ℃. The ES-20/80 has a settable speed control range of 50-400 rpm (in 10rpm increments).
• Up to 3 units can be stacked, which enables you to save space. The new clear touchscreen display and simple interface provide a clear and intuitive control of parameters. It also allows data logging, storage and displays over time.
• Bluetooth® connectivity to PC allows for data management, data logging, parameter control and profiling in the included software.
• Available with 5 interchangeable platforms and stacking kits. Must be ordered separately.
