| Optics |
Grid monochromator with reference beam and beam splitter after exit slit |
| Light Source |
Xenon flash lamp (500 million flashes possible) |
| Measurement |
Concentration, single and multi-wavelength measurement of absorbance and % transmission, kinetics, spectra |
| Wavelength Range |
190 - 1100 nm（nm) |
| Wavelength Resolution |
1 nm |
| Wavelength Accuracy |
± 1 nm on all Holmium peaks |
| Wavelength Reproducibility |
better than 0,5 nm |
| Spectral Scope |
4 nm |
| Photometric Range |
-3.3 - +3.3 Abs |
| Photometric Resolution |
Absorption: 0.001 ; Transmission: 0.1 % |
| Photometric Accuracy |
0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs |
| Photometric Reproducability |
0.003 Abs below 0.6 Abs ; 0.5 % from 0.6 to 2.0 Abs |
| Photometric Linearity |
< 1 % up to 2.0 Abs between 340 to 900 nm |
| Scan Speed |
700 - 2000 nm/min. |
| Drift |
< 0.005 Abs per hour after 15 minutes heat up time |
| Stray Light |
< 0.05 % Transmission at 340 and 408 nm |
| Suitable Vials |
Rectangular Cuvettes 10 mm |
| Rectangular Cuvettes 20 mm |
| Rectangular Cuvettes 50 mm |
| Round Cuvettes 13 mm |
| Round Cuvettes 16 mm |
| Round Cuvettes 24 mm |
| Display |
7“ high contrast colour graphic-display |
| Interfaces |
Ethernet |
| USB B |
| USB A for External Memory |
| Keypad |
| Barcode-Scanner |
| PCL Compatible Printer |
| Operation |
Membrane Keyboard |
| Automatic Cuvette Recognition |
Round cuvettes: 13, 16 and 24 mm ; Rectangular cuvettes: 10, 20 and 50mm |
| Auto – OFF |
Yes |
| Test Recognition |
via internal barcode reader |
| Programmability |
up to 100 user programms, 20 user profiles, > 150 preprogrammed methods |
| Auto-Check |
Self-test at each switch-on: test of memory, processor, internal interface, filter lamp and additional calibration of each wavelength |
| LIMS Compatibility |
ASCII, .csv-files |
| Internal Storage |
approx. 5000 data sets (method, user ID, date, result), autostorage function / manual storage function |
| Security |
Password protection possible: 3 different user levels (guest, user, admin) |
| Power Drain |
100 - 240 V, 50/60 Hz |
| Power Supply |
Buffer batteries (4 x AA), power supply unit with cable |
| Portability |
Benchtop |
| Environmental Conditions |
+10 °C to 35 °C (41 °F to 95 °F), |
| ≤ 75 % average humidity within one year 95 %, max. 30 days/year, 85 % all other days |
| Stock Conditions |
-25 °C to +65 °C (-13 °F to 268 °F) |
| IP Rating |
IP 30 |
| Compliance |
CE |
| Interference Emission |
Class B |
| Interference Immunity |
IEC 61000-4-3 |
| Tolerance Extension |
0.008 E |
| Meter Safety |
EC Directive 2014/35/EC EN 61010-1:2010 |
| Languages User Interface |
German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian |
| Languages Quick Start Guide |
German, English, French, Spanish, Italian, Portuguese, Polish, Indonesian, Russian, Chinese, Japanese, Dutch, Swedish, Norwegian, Czech, Romanian, Macedonian, Slovenian, Hungarian, Turkish, Korean, Vietnamese, Thai, Serbian, Malaysian, Danish, Bulgarian |
| Languages Full User Manual |
German, English, Spanish, French, Italian, Portuguese, Chinese, Japanese |
| Dimensions |
422 x 195 x 323 mm |
| Weight |
4.5 kg |
