The AE31 Elite is a professional inverted microscope providing high image quality, ergonomic design and advanced illumination features. The AE31E is the ideal platform for routine microbiology applications in clinical, pharmaceutical laboratories and university research environments.
In full accordance with Motic's CCIS© Infinity System, LWD Plan Achromatic objectives with an intelligent phase contrast concept deliver a high quality image. The AE31E stand carries an encoded 5-fold nosepiece with a light memory function. The illumination intensity for each objective position is memorised and replicated once the respective objective is swung in again. Rich illumination power is provided by the 30 Watt Halogen light source in a Full-Koehler configuration, interchangeable with 3W LED modules of different colour temperatures.
The Auto ON/OFF function, based on a built-in IR-sensor, deactivates the microscope in case it is left on by the user.Specification:Colour Corrected Infinity Optical System (CCIS®); 48-75mm Interpupillary distance; Eyepieces: WF10X/22mm with diopter adjustment, +/- 5 diopter; Objective classification: Infinity Corrected CCIS Plan Achromat, DIN; Objectives: 4X/0.10 (WD 23.5mm), PH10X/0.25 (WD 7.5mm), LWD PH20X/0.40 (WD 7.0mm),LWD PH40X/0.50 (WD 3.0mm); Stage size: 200x239mm; Illumination: External lamphouse, 6V/30W Quartz Halogen or 3W LED Koehler illumination with intensity control.
