Incident light microscope for material sciences - Panthera TEC MAT BF is a microscope with a set of long distance plan achromatic and semi-apo objectives, working with UC eyepieces of 22mm field of view. The Motic LightTracer system with memory function, a built in low energy mode and an LED feedback indicator helps to optimise your workflow.

The AE31 Elite is a professional inverted microscope providing high image quality, ergonomic design and advanced illumination features. The AE31E is the ideal platform for routine microbiology applications in clinical, pharmaceutical laboratories and university research environments.

The BA310 for use in Universities, Clinics, Laboratories, and any other life science or medical application. Using Motic's Colour Corrected Infinity Optics (CCIS®) with EC Plan Achromats, this model's full Koehler configuration provides maximum illumination quality for even the most demanding samples. The BA310 is also upgradeable to include additional contrast methods and discussion devices.

The SLS Lab Basics Max III Binocular Compound Microscope (4x, 10x, 40x, 100x Plan Achromatic) is known for its robust construction and simple operation. This durable microscope is an excellent choice for carrying out everyday applications in teaching laboratories. It is equipped with four high clarity Plan Achromatic objectives. This microscope also has a fixed wide-field 10x eyepiece, a quadruple reversed nosepiece, mechanical stage, and Brightfield Abbe condenser. With a bright white 3W LED light source, this microscope can produce dramatic and high-quality images.

The AE31 Elite is a professional inverted microscope providing high image quality, ergonomic design and advanced illumination features. The AE31E is the ideal platform for routine microbiology applications in clinical, pharmaceutical laboratories and university research environments.

The SLS Lab Basics Max III Trinocular Compound Microscope (4x, 10x, 40x, 100x Infinity Corrected Plan Achromatic) is professionally designed for laboratory applications in teaching laboratories, offering precise high-quality images with its fully-coated optical system. This microscope comes with an inclined 30 and 360 rotatable trinocular head and a built-in mechanical stage. Four high clarity Infinity Corrected Plan Achromatic objectives are supplied as standard.

• Integral carrying handle allows for one handed transportation of the microscope
• Precondenser: fixed lens, which is removable to accept a mirror (for locations without power) and to allow for lamp replacement
• All objectives are colour coded to ease identification when in use
• Reversed nosepiece and full mechanical stage: quadruple reversed, so providing easy uninterrupted access to the stage when changing over slides, has full X/Y movement and spring loaded slide holder
• Optical head: trinocular with photo port inclined at 30, interpupillary distance adjustment (Siedentopf type): 47 to 78mm, dioptric adjustment on one eyepiece
• Eyepieces: 10x/18mm wide-field (pointer in one eyepiece)
• Nosepiece: quadruple reversed, revolving with click stop
• Objectives: 4x, 10x, 40x, 100x infinity corrected plan achromatic
• Condenser: brightfield Abbe NA 1.25 - precentred, focusable, iris diaphragm and filter holder
• Stage: 160 x 140mm with built-in mechanical stage and slide holder, 75 x 50mm movement, Vernier scale
• Focusing knobs: coaxial coarse and fine with stop
• Mains power: 220 - 240V / 50 - 60Hz
• Converter: built-in low voltage (3.2 - 3.5V electric)
• Illumination: LED 3W with intensity control
• Supplied with: immersion oil (5mL), blue filter, dust cover, power cord with unique 'self-store' system, and instruction manual

The BA310 for use in Universities, Clinics, Laboratories, and any other life science or medical application. Using Motic's Colour Corrected Infinity Optics (CCIS®) with EC Plan Achromats, this model's full Koehler configuration provides maximum illumination quality for even the most demanding samples. The BA310 is also upgradeable to include additional contrast methods and discussion devices.

Simple add on polariser - suitable for a range of Motic microscopes.

The AE31 Elite is a professional inverted microscope providing high image quality, ergonomic design and advanced illumination features. The AE31E is the ideal platform for routine microbiology applications in clinical, pharmaceutical laboratories and university research environments.

• Eyepiece Tubes - Viewing angle of 30°, 22 mm Field of View with interpupillary distance adjustable between 50-75mm
• Eyepieces - Infinity Corrected CCIS® Optics with a field flatness up to 22mm and the high eye point ensure true colour and sharp images and minimise eye fatigue and strain
• Objectives - New class of EC-H optics for Bright Field and Phase Contrast incorporate multi-layer coated glass for enhanced contrast and spherical aberration correction to significantly improve field flatness and improve resolution
• Stage - New Rackless low position coaxial mechanical stage with sample holder and ceramic insert. Mechanical travel range from 80 x 55 mm
• Light features: Auto-OFF and Light Memory function
• Illumination - Externally mounted lamphouse, 12V/50W Quartz Halogen Koehler illumination with intensity control. A 12V/100W Koehler system is also available
• Phase Contrast & Darkfield –Options include a slider solution or a turret condenser for more advanced Phase contrast demands
• Polarisation - Polarisation can be achieved using 2 slots in the upper part of the stand which can accommodate a rotatable analyser, retardation plate (First Order Red Compensator) and a polarizer placed on top of the collector
• Fluorescence – Easily upgradeable to an EPI-Fluorescence microscope by using the fluorescence attachment which can carry up to 4 filter cubes. A complete range of filter cubes is available, covering all routine applications from UV up to NIR

The AE31 Elite is a professional inverted microscope providing high image quality, ergonomic design and advanced illumination features. The AE31E is the ideal platform for routine microbiology applications in clinical, pharmaceutical laboratories and university research environments.

Huygens eyepiece H5X/14.5mm

Designed as a basic instrument for any life-science laboratory, the inverted AE2000 comes with a Binocular stand. With a surprisingly small footprint, Motic AE2000 fits easily into every laboratory even when space is limited. A robust design and solid manufacturing ensure a long working life time even under rough usage conditions. Easy reach of both focusing and illumination controls guarantee comfortable operation for many hours.

New transmitted light workstation for the investigation of birefringent samples. Includes a set of new UC plan achromatic (strain free) objectives and eyepieces of 22mm field of view. The Motic LightTracer system with memory function, a built in low energy mode and an LED feedback indicator helps to optimise your workflow.
