The Funke Gerber LactoFlash is an accurate, reliable instrument for rapid analysis of the main constituents of milk. It directly measures Fat and S.N.F. (Solid Non Fat) and then calculates Density, Protein, Lactose and Freezing Point.
Countless installations in institutes and laboratories all over the world attest to the outstanding quality, reliability and accuracy of this chemical analysis device.The following parameters can be determined quickly and reliably with just one measurement:
| Parameter |
Resolution |
Reproducibility(r) |
Measuring Range |
| Fat |
0.01% |
0.02% in 0 ... 5% range 0.2 % in 5 ... 30 % range |
0 ... 30% |
| SNF |
0.01% |
0.04% |
0 ...15% |
Further parameters are determined based on calculational algorithms:
| Parameter |
Resolution |
Reproducibility(r) |
Measuring Range |
| Density |
0.0001 |
0.001 |
no limit |
| Protein |
0.01% |
0.03% |
no limit / calculated value |
| Lactose |
0.01% |
0.02% |
no limit / calculated value |
| Gpp |
0.001oC |
0.002oC |
no limit / calculated value |
Specification
| Technical Specification |
| Sample capacity: |
up to 120/h |
| Sample volume: |
from 12 ml to 20 ml |
| Interfaces: |
1 x parallel, 1 x serial (RS 232 / 9.600 baud), USB 6 volt electrical power supply for thermal printer |
| Connection values: |
230V / 115V AC (50...60 Hz) 180 W |
| Dimensions: |
30 x 24 x 33 cm (w x h x d) |
| Weight: |
5 kg (net) |
