The Funke Gerber LactoFlash is an accurate, reliable instrument for rapid analysis of the main constituents of milk. It directly measures Fat and S.N.F. (Solid Non Fat) and then calculates Density, Protein, Lactose and Freezing Point.
Countless installations in institutes and laboratories all over the world attest to the outstanding quality, reliability and accuracy of this chemical analysis device.The following parameters can be determined quickly and reliably with just one measurement:
Parameter
Resolution
Reproducibility(r)
Measuring Range
Fat
0.01%
0.02% in 0 ... 5% range 0.2 % in 5 ... 30 % range
0 ... 30%
SNF
0.01%
0.04%
0 ...15%
Further parameters are determined based on calculational algorithms:
Parameter
Resolution
Reproducibility(r)
Measuring Range
Density
0.0001
0.001
no limit
Protein
0.01%
0.03%
no limit / calculated value
Lactose
0.01%
0.02%
no limit / calculated value
Gpp
0.001oC
0.002oC
no limit / calculated value
Specification
Technical Specification
Sample capacity:
up to 120/h
Sample volume:
from 12 ml to 20 ml
Interfaces:
1 x parallel, 1 x serial (RS 232 / 9.600 baud), USB 6 volt electrical power supply for thermal printer
